Kо̄manawa NZ Depth to Water#

a small repo that holds:

  • The code used to produce a New Zealand wide depth to water dataset

  • Versioning of and access to the dataset

  • Full documentation of the dataset

Author:

Patrick Durney, Matt Dumont, Evelyn Charlesworth

copyright:

2024, Kо̄manawa Solutions Ltd.

Version:

v0.1.4

Date:

Aug 11, 2025

Changelog entry:

Initial release of the dataset

Data access:

Access the data via this package.

Data Last updated:

2024-09-19

Limitations#

While we have made every attempt to ensure the quality of the data and code in this repository, we do not provide any explicit or implicit guarantee of the datasets produced or methods provided here. In addition, by proving the base data, the data providers have also not provided any explicit or implicit guarantee of these data. Data errors will inevitably exist in the dataset, and we encourage users to report these errors to us so that we can correct them.

We are aware of limitations of this work which are listed below:

  • We have made a series of assumptions during the data processing; these are discussed above.

  • The data is only as good as the data provided by the provider or sourced by Kо̄manawa; we did not have the resources nor all the information to fully quality-assure the data.

  • No data provider has provided any explicit or implicit guarantee of the data they have provided and cannot be held liable for any inaccuracies, errors, or omissions in the dataset.

  • For many sites, the elevation of the measuring point is unknown. We have used LiDAR data to estimate the elevation of the ground, but this will likely reduce the accuracy of the groundwater elevation depending on the resolution of the LiDAR data.

  • We have assumed that the depth to water from ground level is correct, and therefore any errors in the depth to water data will be reflected in the groundwater elevation values.

  • There may be unknown regional data handling/reporting peculiarities that we were not aware of that could affect the data.

  • The dataset is not exhaustive, and there may be more data available that has not been included in this dataset.

Additionally the dataset is a static snapshot of the available data as of September 2023. Datasets typically are updated and improved over time, and this dataset may not reflect the best available data at the time of use. We encourage users to check the original data sources for the most up-to-date information. Should differences be found between this dataset and data accessed more recently from the original sources, this dataset should be assumed to be incorrect. We encourage users to report these differences via the issues page on the GitHub repository. We make no guarantee to address these issues; however open issues will serve a purpose by informing other users of potential issues with the dataset.

Before using the data please ensure you fully understand these limitation, the limitations of the original data sources, and check for any potential issues raised by other users in the issues page of the GitHub repository.

How to Cite:#

Durney, P., Charlesworth, E., & Matt, D. (2024). Developing a national groundwater level dataset for New Zealand. Journal of Hydrology (New Zealand), 63(1), 51-68.

BibTeX:

@article{durney2024developing,
      title={Developing a national groundwater level dataset for New Zealand},
      author={Durney, Patrick and Charlesworth, Evelyn and Matt, Dumont},
      journal={Journal of Hydrology (New Zealand)},
      volume={63},
      number={1},
      pages={51--68},
      year={2024},
      publisher={New Zealand Hydrological Society (Inc.) Wellington, NZ}}

Data Access via Python#

Installation#

Option 1 - pip

pip install git+https://github.com/Komanawa/komanawa-nz-depth-to-water.git

Option 2 - clone the repository

clone the repository and install the package as you see fit.

Option 3 - Fork the repository

Fork the repository and modify and use the code as you see fit. If you have any improvements, please submit a pull request.

Code Example#

from komanawa.nz_depth_to_water import get_nz_depth_to_water
water_level_data, metadata = get_nz_depth_to_water()

Export the data to a csv files#

To export the data to a csv file, you can use the following code (assuming you have installed the package):

python -m komanawa.nz_depth_to_water.export_to_csv

Alternatively, you can specify a folder to export the data:

python -m komanawa.nz_depth_to_water.export_to_csv /path/to/folder

Contributing and issues/bugs#

We have made every attempt to ensure the quality of the data and code in this repository. However, inevitably, there will be issues with the data or code. If you find an issue, please raise an issue on the GitHub repository. If you would like to contribute to the code or data, please fork the repository and submit a pull request.

Higher Precision Data#

The dataset that is held in this repository is a highly compressed version, but the compression is lossy. Here all data is stored with a precision of 0.1 m. We have also produced a higher precision version of the dataset, which holds the data with 5 decimal places (0.00001 m). This dataset is too large to store in this repository, but is available on request.

To use the higher precision data (once the you have the netcdf file), you can use the following code:

from komanawa.nz_depth_to_water import get_nz_depth_to_water
water_level_data, metadata = get_nz_depth_to_water(ncdataset_path="path/to/higher_precision_data.nc")

Water Level Data column meanings/metadata#

  • wl_site_name

    • long_name: site name

    • description: name of the site, the flag values and meanings are enumerate(ds[“site_name”][:])

    • units: None

  • wl_date

    • _FillValue: 0

    • long_name: water level sampling date

    • units: days since 1899-01-01T00:00:00

    • missing_value: 0

    • origin: 1899-01-01T00:00:00

    • description: Note there are significant numbers of observations in 1900, this is likely a placeholder date, but we have not converted to NAN as it is unclear

  • wl_gw_elevation

    • long_name: ground water elevation

    • units: m

    • description: The groundwater elevation at the site on the date provided. Provided by the data provider, otherwise calculated if a groundwater depth reading

    • scale_factor: 0.1

    • add_offset: 0

    • datum: NZVD2016

    • missing_value: -32768

  • wl_depth_to_water

    • long_name: depth to water

    • units: m

    • description: The depth to water reading at the site on the date provided to either ground level or measuring point. Provided by the data provider, otherwise calculated if a groundwater elevation was provided.

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • wl_depth_to_water_cor

    • long_name: depth to water corrected

    • units: m

    • description: Depth to water from from ground surface e.g. corrected for collar height if available.

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • wl_water_elev_flag

    • long_name: water elevation quality flag

    • flag_values:

      • 0: no_data

      • 1: logger

      • 2: manual

      • 3: static_oneoff

      • 4: aquifer_test

      • 5: other

    • units: None

  • wl_dtw_flag

    • long_name: depth to water quality flag

    • flag_values:

      • 0: no_data

      • 1: logger

      • 2: manual

      • 3: static_oneoff

      • 4: calculated_from_gw_elevation

      • 5: aquifer_test

      • 6: other

    • units: None

Metadata column meanings/metadata#

  • site_name

    • long_name: name of the site

    • description: A unique identifier for each well, combining the well name and the source provider, where the well name is the name provided by the data provider and the source provider is the name of the data provider. For example, a well named “well1” from the source “source1” would have a site name of “well1_source1”.

    • units: None

  • rl_source

    • _FillValue: 0

    • long_name: source of reference level data (if not supplied)

    • flag_values:

      • 1: marlborough/marlborough_2018

      • 2: marlborough/marlborough_2020-2022

      • 3: marlborough/blenheim_2014

      • 4: canterbury/kaikoura_2016-2017

      • 5: manawatu-whanganui/whanganui-urban_2020-2021

      • 6: 8m_dem

      • 7: wellington/kapiti-coast_2021

      • 8: manawatu-whanganui/manawatu-whanganui_2022-2023

      • 9: manawatu-whanganui/manawatu-whanganui_2015-2016

      • 10: southland/southland_2020-2023

      • 11: manawatu-whanganui/palmerston-north_2018

      • 12: wellington/wellington_2013-2014

      • 13: hawkes-bay/hawkes-bay_2020-2021

      • 14: waikato/waikato_2021

      • 15: waikato/thames_2017-2019

      • 16: auckland/auckland-south_2016-2017

      • 17: taranaki/taranaki_2021

      • 18: waikato/hamilton_2019

      • 19: waikato/huntly_2015-2019

      • 20: auckland/auckland-north_2016-2018

      • 21: waikato/reporoa-and-upper-piako-river_2019

      • 22: bay-of-plenty/bay-of-plenty_2019-2022

      • 23: canterbury/christchurch_2020-2021

      • 24: northland/northland_2018-2020

      • 25: canterbury/canterbury_2020-2023

      • 26: canterbury/banks-peninsula_2023

      • 27: otago/coastal-catchments_2021

      • 28: wellington/hutt-city_2021

      • 29: canterbury/selwyn_2023

      • 30: canterbury/canterbury_2018-2019

      • 31: wellington/upper-hutt-city_2021

      • 32: nelson/top-of-the-south-flood_2022

      • 33: wellington/wellington-city_2019-2020

      • 34: tasman/tasman-bay_2022

      • 35: tasman/abel-tasman-and-golden-bay_2023

      • 36: otago/wanaka_2022-2023

      • 37: otago/otago_2016

      • 38: otago/central-otago_2022-2023

      • 39: wellington/porirua_2023

      • 40: hawkes-bay/gisborne-and-hawkes-bay-cyclone-gabrielle-river-flood_2023

      • 41: canterbury/timaru-rivers_2014

      • 42: west-coast/west-coast_2020-2022

      • 43: gisborne/gisborne_2023

      • 44: canterbury/hurunui-rivers_2013

      • 45: otago/queenstown_2021

      • 46: canterbury/christchurch-and-ashley-river_2018-2019

      • 47: canterbury/kaikoura-and-waimakariri_2022

      • 48: canterbury/canterbury_2016-2017

      • 49: canterbury/hawarden_2015

      • 50: canterbury/mackenzie_2015

      • 51: otago/central-otago_2021

      • 52: tasman/tasman_2020-2022

      • 53: gisborne/gisborne_2018-2020

      • 54: tasman/tasman_2008-2015

      • 55: southland/stewart-island-rakiura-oban_2021

      • 56: tasman/motueka-river-valley_2018-2019

      • 57: tasman/golden-bay_2017

      • 58: canterbury/christchurch-and-selwyn_2015

      • 59: otago/queenstown_2016

      • 60: otago/balclutha_2020

    • description: reference level was filled with the best avalible DEM source. A values like “canterbury/selwyn_2023” means the reference level was filled with LIDAR from the canterbury/selwyn survey in 2023 see: linz/elevation. A value of “8m dem” means the reference elevation was filled with https://data.linz.govt.nz/layer/51768-nz-8m-digital-elevation-model-2012/

    • missing_value: 0

    • units: None

  • source

    • _FillValue: 0

    • long_name: source of data

    • flag_values:

      • 1: mdc

      • 2: hrc

      • 3: src

      • 4: gwrc

      • 5: wrc

      • 6: auk

      • 7: nzgd

      • 8: nrc

      • 9: bop

      • 10: wcrc

      • 11: ecan

      • 12: orc

      • 13: gdc

      • 14: trc

      • 15: tdc

      • 16: ncc

      • 17: hbrc

      • 18: tcc

    • missing_value: 0

    • units: None

  • nztm_x

    • long_name: x coordinate

    • units: m

    • epsg: 2193

  • nztm_y

    • long_name: y coordinate

    • units: m

    • epsg: 2193

  • reading_count

    • long_name: number of readings

    • units: count

  • mean_gwl

    • long_name: mean ground water level

    • units: m

    • datum: NZVD2016

    • description: calculated from this dataset for ease of use

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • median_gwl

    • long_name: median ground water level

    • units: m

    • datum: NZVD2016

    • description: calculated from this dataset for ease of use

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • std_gwl

    • long_name: std ground water level

    • units: m

    • datum: NZVD2016

    • description: calculated from this dataset for ease of use

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • max_gwl

    • long_name: max ground water level

    • units: m

    • datum: NZVD2016

    • description: calculated from this dataset for ease of use

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • min_gwl

    • long_name: min ground water level

    • units: m

    • datum: NZVD2016

    • description: calculated from this dataset for ease of use

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • well_depth

    • long_name: well depth

    • units: m

    • description: The depth of the well, if known, as provided by the data provider. There is not clarity on what this value represents, it may be the depth of the well screen, or the depth of the well casing, or the depth of the well itself and it may be from the ground surface, the measurement point, or similar

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -2147483648

  • bottom_bottomscreen

    • long_name: bottom of bottom screen

    • units: m

    • description: The depth of the end of the bottom screen, if known. If there is only one screen in the well, the end of screen depth will be recorded in bottom_topscreen. If there is more than one screen in the well, this value is the depth at which the last screen ends. It is unclear if this value is from the ground surface, the measurement point, or similar.

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -2147483648

  • dist_mp_to_ground_level

    • long_name: distance from measurement point to ground level

    • units: m

    • description: The distance from the measuring point to the ground surface, if known. If it is 0, the measuring point is at the ground surface.

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • rl_elevation

    • long_name: reference level elevation

    • units: m

    • description: The elevation of the reference level, if known.

    • datum: NZVD2016

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • top_topscreen

    • long_name: top of top screen

    • units: m

    • description: The depth of the top of the top screen, if known. If there is only one screen in the well, the top of screen depth will be recorded in top_topscreen. If there is more than one screen in the well, this value is the depth at which the first screen starts. It is unclear if this value is from the ground surface, the measurement point, or similar.

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -2147483648

  • mean_dtw

    • long_name: mean depth to ground water level

    • units: m

    • description: calculated from this dataset for ease of use

    • convention: positive values (+) are below the ground surface, negative values (-) are above the ground surface (artesian)

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • median_dtw

    • long_name: median depth to ground water level

    • units: m

    • description: calculated from this dataset for ease of use

    • convention: positive values (+) are below the ground surface, negative values (-) are above the ground surface (artesian)

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • std_dtw

    • long_name: std depth to ground water level

    • units: m

    • description: calculated from this dataset for ease of use

    • convention: positive values (+) are below the ground surface, negative values (-) are above the ground surface (artesian)

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • max_dtw

    • long_name: max depth to ground water level

    • units: m

    • description: calculated from this dataset for ease of use

    • convention: positive values (+) are below the ground surface, negative values (-) are above the ground surface (artesian)

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • min_dtw

    • long_name: min depth to ground water level

    • units: m

    • description: calculated from this dataset for ease of use

    • convention: positive values (+) are below the ground surface, negative values (-) are above the ground surface (artesian)

    • scale_factor: 0.1

    • add_offset: 0

    • missing_value: -32768

  • start_date

    • _FillValue: 0

    • long_name: start date

    • units: days since 1899-01-01T00:00:00

    • missing_value: 0

    • origin: 1899-01-01T00:00:00

    • description: start date of the reading calculated from this dataset for ease of use

  • end_date

    • _FillValue: 0

    • long_name: end date

    • units: days since 1899-01-01T00:00:00

    • missing_value: 0

    • origin: 1899-01-01T00:00:00

    • description: end date of the reading calculated from this dataset for ease of use

Source key#

Source

Full name

auk

Auckland Council

bop

Bay of Plenty Regional Council

gdc

Gisborne District Council

hbrc

Hawkes Bay Regional Council

hrc

Horizons Regional Council

mdc

Marlborough District Council

nrc

Northland Regional Council

ncc

Nelson City Council

orc

Otago Regional Council

src

Environment Southland

trc

Taranaki Regional Council

tdc

Tasman District Council

tcc

Tauranga City Council

wc

Waikato Regional Council

gwrc

Greater Wellington Regional Council

wcrc

West Coast Regional Council

nzgd

New Zealand Geotechnical database

ecan

Environment Canterbury
On this page
